Heavy Duty Differential AGV Motor Wheel Suitable for 400W Motors & Load 800kg
Voltage: 48V
Rated Load: 800kg
Rated Torque: 42 N·m
Drive Wheel Diameter: 120mm
Pairs well with
Heavy Duty Differential AGV Motor Wheel Suitable for 400W Motors & Load 800kg
Heavy-duty AGV Differential Motor Wheel supports up to 800 kg load with 42 Nm rated and 84 Nm maximum torque, ensuring stable operation under heavy conditions. It features excellent maneuverability with a 270 mm turning diameter, ±130° mechanical limit, and ±5° yaw angle. The wheel offers high efficiency with a speed ratio of 18 and maximum speed of 62.8 m/min. Its IP54 rating and operation range of -25°C to +90°C ensure adaptability in harsh environments. With a 400W power rating, 48V DC voltage, and low maintenance grease lubrication, it provides precise control and durability for various AGV/AMR applications.
High Load Capacity: Heavy-duty Differential AGV Motor Wheel has a rated load of 800 kg, rated torque of 42 Nm, and maximum torque of 84 Nm, ensuring stable AGV operation under heavy loads.
Excellent Maneuverability and Flexibility: With a small turning diameter of 270 mm, mechanical limit angle of ±130°, and maximum yaw angle of ±5°, this wheel allows the AGV to navigate tight spaces and improves workplace space utilization.
High Efficiency and Stability: Featuring a speed ratio of 18 and a maximum speed of 62.8 m/min, the polyurethane drive wheel provides excellent wear resistance and grip for stable, efficient operation.
Precise Positioning and Safety: The BRT38-COM4096D16-RT steering encoder and 16:100 gear ratio ensure accurate steering, while the built-in braking device enhances positioning and parking reliability.
Adaptable to Harsh Environments: With an IP54 rating, this wheel performs in dustproof, waterproof environments and maintains operation from -25°C to +90°C, adapting to complex conditions.
High Energy Efficiency and Low Maintenance: Rated at 400W, with a 48V DC voltage and 10.6 A current, and grease lubrication, it offers low maintenance and stable long-term operation, reducing operational costs.
Wide Applicability: Ideal for various AGV/AMR types, this wheel excels in high-load, high-mobility, and harsh environment applications.
Differential AGV Motor Wheel Specification:
| Model:HKT-DW-120-18-400 | |
| Motor Parameters | |
| Rated Power | 400W |
| Rated Torque | 1.27Nm |
| Voltage | 48V DC |
| Rated Current | 10.6A |
| Rated Speed | 3000r/min |
| With Brake Or Not | Yes |
| Reducer Parameters | |
| Speed Ratio | 18 |
| Rated Torque | 42Nm |
| Max.Torque | 84Nm |
| Lubrication Method | Grease Lubrication |
| Machine Parameters | |
| Drive Wheel Diameter | 120mm |
| Rated Load | 800kg |
| Max.Speed | 62.8m/min |
| Turning Diameter | 270mm |
| Mechanical Limit Angle | ±130° |
| Max.Yaw Angle | ±5° |
| Drive Wheel Material | Polyurethane |
| Steering Encoder Model | BRT38-COM4096D16-RT |
| Steering Encoder Gear Radio | 16:100 |
| ProtectionGrade | IP54 |
| Operation Temperature | -25C°~+90C° |
